Eyelet65는 Linea Light의 컴팩트하고 다재다능한 매립형 스포트라이트로, 실내외 설치에 적합합니다. 원형 또는 사각형 버전으로 제공되며,  다양한 옵틱 옵션을 통해 다양한 조명 효과를 연출할 수 있습니다. IP65 등급을 받아 내구성이 뛰어나며, 벽, 천장, 바닥 등 다양한 장소에 설치할 수 있습니다. 또한 2700K, 3000K, 4000K의 색온도로 제공되어 다양한 분위기의 조명이 가능합니다.

Gypsum Coloring Point is an innovative spotlight designed to combine customization and high performance. Its paintable gypsum base and interchangeable ABS rings, available in various finishes, allow for a personalized look. The body is made of wrinkled white or black painted aluminum and offers two optic options (24° and 42°), with a tilt of up to 90° and a 350° rotation. Available with an integrated or non-integrated driver, it provides versatile lighting to adapt to various settings.





Size Watts  Code Color
Temp.		 Source –
Delivered		 Optic








































3W DC
1000mA





































 C01045-WH-M-FL
 M
2700K		 358 LM-
287 LM (FL)		 23.4°
C01045-WH-M-ML
 358 LM-
278 LM (ML)		 31°
C01045-WH-M-WF
 358 LM-
279 LM (WF)		 53°
C01045-WH-W-FL
 W
3000K		 402 LM-
322 LM (FL)
 23.4°
C01045-WH-W-ML
 402 LM-
312 LM (ML)		 31°
C01045-WH-W-WF
 402 LM-
313 LM (WF)		 53°
C01045-WH-N-FL
 N
4000K		 417 LM-
334 LM (FL)		 23.4°
C01045-WH-N-ML
 417 LM-
324 LM (ML)		 31°
C01045-WH-N-WF
 417 LM-
325 LM (WF)		 53°
C01045-BB-M-FL
 M
2700K		 358 LM-
287 LM (FL)		 23.4°
C01045-BB-M-ML
 358 LM-
278 LM (ML)		 31°
C01045-BB-M-WF
 358 LM-
279 LM (WF)		 53°
C01045-BB-W-FL
 W
3000K		 402 LM-
322 LM (FL)
 23.4°
C01045-BB-W-ML
 402 LM-
312 LM (ML)		 31°
C01045-BB-W-WF
 402 LM-
313 LM (WF)		 53°
C01045-BB-N-FL
 N
4000K		 417 LM-
334 LM (FL)		 23.4°
C01045-BB-N-ML
 417 LM-
324 LM (ML)		 31°
C01045-BB-N-WF
 417 LM-
325 LM (WF)		 53°
C01045-DB-M-FL M
2700K		 358 LM-
287 LM (FL)		 23.4°
C01045-DB-M-ML
 358 LM-
278 LM (ML)		 31°
C01045-DB-M-WF
 358 LM-
279 LM (WF)		 53°
C01045-DB-W-FL
 W
3000K


 402 LM-
322 LM (FL)		 23.4°
C01045-DB-W-ML
 402 LM-
312 LM (ML)		 31°
C01045-DB-W-WF
 402 LM-
313 LM (WF)		 53°
C01045-DB-N-FL N
3000K


 417 LM-
334 LM (FL)		 23.4°
C01045-DB-N-ML
 417 LM-
324 LM (ML)		 31°
C01045-DB-N-WF
 417 LM-
325 LM (WF)		 53°
C01045-GG-M-FL M
2700K
 358 LM-
287 LM (FL)		 23.4°
C01045-GG-M-ML
 358 LM-
278 LM (ML)		 31°
C01045-GG-M-WF
 358 LM-
279 LM (WF)		 53°
C01045-GG-W-FL W
3000K		 402 LM-
322 LM (FL)		 23.4°
C01045-GG-W-ML
 402 LM-
312 LM (ML)		 31°
C01045-GG-W-WF 402 LM-
313 LM (WF)		 53°
C01045-GG-N-FL

N
4000K		 417 LM-
334 LM (FL)		 23.4°
C01045-GG-N-ML
 417 LM-
324 LM (ML)		 31°
C01045-GG-N-WF
 417 LM-
325 LM (WF)		 53°





























































Finish BB (Black), WH (White), GG (Grey), IS (Steel), DB (Dark Brown), BG (Black Grey)
Color Temp. M (2700K), W (3000K), T (3500K), N (4000K), C (5000K), Dynamic White (2700–5700K), Z (RGB)
Beam Angle NS (Narrow Spot), SP (Spot), FL (Flood), ML (Medium Flood), MW (Medium Wide Flood), DI (Diffused),
ES (Elliptic Spot)
